• New best-in-class power modules based on the latest silicon carbide technology (SiC), which allows for more compact, more reliable and more robust solutions.
• Ultra-high efficiency up to 98.1% in ON LINE double conversion, providing the best power supply to critical equipment.
• Minimized total cost of ownership thanks to the lowest operational expenses on the market.
• Reduced demand and consumption of cooling systems.

• Two versions of 3U 67 kW Power Modules: the standard PM (IGBT) can reach up to 96.5% efficiency, whereas the BLUE (SiC) PM boasts outstanding efficiency of 98.1% in ON LINE Mode.
• Easy scalability to optimise both the initial investment and the TCO (total cost of ownership). The range consists of:
  • MP2 300 up to 300 kW;
  • MP2 500 up to 500 kW;
  • MP2 600 up to 600 kW.
• PMs are designed to be fully independent, hot-swappable, mechanically segregated and with embedded selective disconnection at both the input and output stage.
• Bypass is modular and fully rated according to the maximum power of the system.

• Intelligence is distributed to ensure the protection of the equipment even on the off chance of a fault on a power module.
• Automatic health-checks are performed during the plug-in of each module to verify its status and avoid defective components.
• Automatic alignment of the firmware when a module with different firmware is inserted.
• Comprehensive upgrade of the firmware can be performed while the unit is working in ON LINE double conversion.
• Continuous monitoring through several sensors embedded in each module, ensuring the best operating performance and bespoke predictive maintenance services based on the actual working conditions.
• Embedded interleaving technology grants a significant reduction of the ripple current values and extends the lifespan of the batteries and DC capacitors.

• Innovative internal communication structure made by two separate and fully redundant high-speed buses.
• Each component of the system, from the modules to the cabinet, is designed and manufactured in Italy.
• All components are carefully selected through a strict approval process.
• All modules and complete units undergo specific tests to verify that each component operates correctly.
• All collected measurements and data is analysed to keep improving our products and provide our customers with the most up to date technologies.
• Enhanced lifespan of the UPS: thanks to embedded status counters, as well as temperature and humidity sensors, providing real-time analytics for operators.

Any increase in power can be done while the unit is working in ON LINE double conversion without any disruption to the load.

The MP2 is available in many configurations and frames:

• PCM: with integrated manual bypass and top-rear ventilation.
• PC0: unit supplied without switches to simplify the integration with the existing electrical infrastructure and to meet any space constraints, available also with top ventilation.
• PCS: fully integrated, for a complete, simple and very reliable installation, with main input, bypass, manual bypass, output switches and top ventilation.

The units have been designed with several standard features:

• Air filter (optional for MP2 300 PCM);
• Fan monitoring;
• Backfeed detection circuit and protection;
• EFFICIENCY CONTROL Mode;
• ACTIVE ECO Mode;
• Power walk-in;
• Separate or common batteries;
• Compatibility with several storage technologies: VRLA, Li-Ion, Supercaps;
• Smart grid ready.

A full set of options is available to fit the requirements of each installation, in both IT and non-IT environments:

• Parallel kit;
• Cold start kit;
• Internal backfeed protection device;
• Bottom cable entry for MP2 500 PCM and MP2 600 PC0;
• Top Cable entry w/ or w/o switches for MP2 300 PCM;
• Synchronisation device (UGS).

All MP2 units are equipped with:

• 10” colour touch screen display that simultaneously provides information, measurements and operating states of the entire system and of each individual power module.
• LED bar which delivers immediate and clear information regarding the current status of the UPS.
• network card NetMan 208C;
• embedded configurable In/Out signals 10 inputs and 8 outputs for MP2 500 and MP2 600 (5 inputs and 4 outputs for MP2 300);
• 2 free slots for the installation of optional communication accessories such as network adaptors and extra volt free contacts;
• R.E.P.O. Remote Emergency Power Off.

The units are also compatible with:

• PowerShield³ monitoring and shutdown software included for Windows operating systems 11, 10, 8, Server 2022, 2019, 2016 and previous versions, Windows Server Virtualization Hyper-V, macOS, Linux, Citrix XenServer and other Unix operating systems;

• Each unit has wheels for a fast and easy positioning;
• Connection terminals are easily accessible from the front;
• All power modules and major components are replaceable in just a few minutes;
• All the major components of the UPS are modular and can be easily added and/or replaced by the engineer, minimising the site intervention costs.
