• A new best-in-class power module, based on the latest silicon carbide (SiC) technology, enables more compact, reliable, and robust solutions.
• Ultra-high efficiency up to 98.1% in ON LINE double conversion, providing the best power supply to critical equipment.
• Minimized total cost of ownership thanks to the lowest operational expenses on the market.
• Reduced demand and consumption of cooling systems.

• Easy scalability to optimise both the initial investment and the TCO (total cost of ownership). The range consists of:
  • M2S 1000 up to 1000 kW;
  • M2S 1250 up to 1250 kW;
  • M2S 1600 up to 1600 kW.
  Each unit is available in several configurations to adapt to existing electrical infrastructure and to meet any space constrains:
  • PC0: unit supplied without switches to simplify the integration with the existing electrical infrastructure.
  • PCS: fully integrated with main input, bypass, manual bypass and output switches.
  • CT0: space-efficient solution with embedded backfeed protection device and without other switches.
  • CT2: unit with backfeed protection device and main input and output switches.
• Two versions of 3U 67 kW Power Modules: the standard PM (IGBT) can reach up to 96.5% efficiency, whereas the BLUE (SiC) PM boasts outstanding efficiency of 98.1% in ON LINE Mode.
• PMs are designed to be fully independent, hot-swappable, mechanically segregated and with embedded selective disconnection at both the input and output stage.
• Bypass is modular and fully rated according to the maximum power of the system.

The units have been designed with several standard features:

• Air filter;
• Fan monitoring;
• Backfeed detection circuit and protection;
• Embedded backfeed Protection device (CT0 & CT2)
• EFFICIENCY CONTROL Mode;
• ACTIVE ECO Mode;
• Power walk-in;
• Separate or common batteries;
• Compatibility with: VRLA, Li-Ion, Supercaps;
• Smart grid ready.

A full set of options is available to fit the requirements of each installation, in both IT and non-IT environments:

• Parallel kit;
• Cold start kit;
• Synchronisation device (UGS);
• Top ventilation (factory option).

• Intelligence is distributed throughout the system, safeguarding the equipment even in rare cases of power module failure.
• Each module undergoes an automatic health-check upon connection, ensuring its proper status and preventing the integration of defective components.
• Firmware automatically aligns when a module with different firmware is inserted.
• The firmware can be fully upgraded while the unit operates in ON LINE double conversion mode.
• Continuous monitoring via multiple sensors within each module optimizes performance and enables tailored predictive maintenance based on real operating conditions.
• Integrated interleaving technology effectively reduces ripple current, extending the life of batteries and DC capacitors.

• An innovative internal communication structure utilizes two independent, fully redundant high-speed buses, ensuring maximum reliability.
• Every system component, from individual modules to the full cabinet, is meticulously designed and crafted in Italy.
• All parts are rigorously vetted through a stringent approval process to guarantee quality and durability.
• Each module and entire unit are tested intensively to verify the optimal functioning of all components.
• Collected data and measurements are continuously analyzed, driving ongoing product enhancement and delivering the latest technology to our customers.
• The UPS’s extended lifespan is supported by embedded status counters and advanced sensors for temperature and humidity, providing real-time analytics for proactive monitoring.

Each M2S unit comes with:

• A 10” colour touchscreen display that clearly shows information, measurements, and operational status of the entire system and each individual power module, all in one place.
• A LED bar provides quick and easy-to-understand updates on the current UPS status.
• NetMan 208 network card.
• Configurable In/Out signals (10 inputs and 8 outputs) for flexible setup.
• Two free slots for optional communication accessories, such as additional network adapters or extra volt-free contacts.
• R.E.P.O. (Remote Emergency Power Off) for immediate emergency shutdown.

The units are also compatible with:

• PowerShield³ monitoring and shutdown software, which supports Windows operating systems (11, 10, 8, Server 2022, 2019, 2016 and older), Windows Server Virtualization Hyper-V, macOS, Linux, Citrix XenServer, and other Unix systems.

• Each unit is designed to simplify positioning, installation, and maintenance tasks.
• Connection terminals are front-accessible, allowing quick and easy access.
• Key UPS components are modular, enabling engineers to easily add or replace parts, significantly reducing on-site intervention costs.
• With built-in intelligence, powerful computing capabilities, and exceptional connectivity, the system allows continuous monitoring of UPS status and offers tailored, proactive services to extend its lifespan.
• The overall design prioritizes simple and efficient maintenance, making upkeep straightforward and cost-effective.
